使用袋泡茶包装机的注意事项及袋泡茶包装机常见故障与排除方法

时间:2017年08月21日信息来源:袋泡茶包装机-www.xmsannong.com 点击: 【字体:

使用袋泡茶包装机的注意事项及袋泡茶包装机常见故障与排除方法
非常感谢您购买我司袋泡茶自动包装机,本操作说明书主要对袋泡茶包装机的正确操作方法及简单故障排除进行介绍,为更好的发挥袋泡茶包装机所具有的功能及维护保养,请在使用前认真阅读袋泡茶包装机说明书后再使用Thank you very much to buy our tea bag packing machine, the operating manual is mainly for the right operation method of the tea bag packing machine and introduces the simple troubleshooting, to better play to the tea bag packaging machine with the function and maintenance, please read carefully before use tea bag packaging machine instruction before using.
使用袋泡茶包装机的注意事项及袋泡茶包装机常见故障与排除方法
一、使用袋泡茶包装机的注意事项:
1.袋泡茶包装机在出厂前各装置及机构配合都经过严格的调试、校对,用户可根据自己的物料和包材特性,对其中某一部分进行调试或改动,确保达到用户的包装要求。请勿随意对袋泡茶包装机某一部分进行调试或改动,如在充分阅读袋泡茶包装机说明书后仍有不清楚之处请与本公司客服部联系。
2.如有对袋泡茶包装机进行局部改进,本袋泡茶包装机说明书内容有时会有不同,请您谅解。
3.袋泡茶包装机说明书对维修部分的内容只进行简单的叙述,确保用户能根据本说明进行调试和维修。如出现机器故障,参考袋泡茶包装机说明书也无法自行排除的,请及时与我公司客服部联系。TEL:153-0698-3059邱经理
使用袋泡茶包装机的注意事项及袋泡茶包装机常见故障与排除方法
二、袋泡茶包装机常见故障与排除方法速查表
故障现象 故障原因 调整及排除方法
部分机构不转动 电机或电机断路 更换或接通
机器运转有异常 有异物落入齿轮或转动部 停机处理
热封合处烧焦 热封辊的轴承部位未加油 齿轮的健脱落开,注油,紧固
包装袋封口不良现象 热封辊的左右压力不均匀 热封合左右压力调整
热封辊有损耗 更换
热封辊封口处不干净 有铜刷清扫
包装纸本身质量问题 与包装纸生产厂家联系
铜套磨损 更换铜套
不封合 加热元件烧毁 更换加热元件
电气元件不良 检查更换
折皱问题和包装膜封边不齐 包装膜的中心线与热辊筒的尺寸不符 见成型器的调整示意图
成型器调整问题 见成型器的调整示意图
封口边有夹料,漏料现象 物料落差时间不同(空气阻力原因) 详见供料与送线时间的调整
装袋时间与热封合时间不协调 详见横封辊的调整及示意图
切口不良 切刀的齿轮磨损 更换
刀刃口不利或破损 更换刀片或用油石修复
动刀与定刀间隙未调节好 调整压紧螺栓
使用袋泡茶包装机的注意事项及袋泡茶包装机常见故障与排除方法
内外袋带线带标袋泡茶包装机,内外袋袋泡茶包装机,袋泡茶内外袋包装机Line inside and outside the bag with the tea bag packing machine, inside and outside the bag of tea bag packaging machine, tea bag inside and outside the bag packaging machine
一、内外袋带线带标袋泡茶包装机,内外袋袋泡茶包装机的适用范围:Line inside and outside the bag with the tea bag packing machine, bag tea bag packaging machine inside and outside of the scope of application:本机适用于茶叶、药茶、保健茶草根类等小颗粒物的内外袋一次性包装。The machine is suitable for tea, herbal tea, health tea grassroots small particles inside and outside the bag, such as disposable packaging.
二、内外袋带线带标袋泡茶包装机,内外袋袋泡茶包装机的本机特点:Line inside and outside the bag with the tea bag packing machine, inside and outside the bag of tea bag packaging machine this machine features:
1.外封纸由步进电机控制,袋长稳定、定位准确;Paper WaiFeng consists of stepper motor control, bag length stable, accurate positioning;
2.采用PID调节温度控制器,温度控制得更准确;Using the PID temperature controller, temperature control more accurate;
3.采用PLC控制整机的动作,人机界面显示,操作方便; PLC control action of the machine, the man-machine interface display, easy to operate;
4.所有可接触物料部分为SUS304不锈钢制作,保证产品的卫生可靠;All parts contacting material of SUS304 stainless steel, ensure health of products;
5.部分工作气缸采用原装进口件,保证其工作准确与稳定。Part of the working cylinder adopts imported parts, ensure the accuracy and stability.
6.本机附加装置可完成平口剪切、日期打印、易撕口等功能。 This machine can complete the flat cutting, date printing, easy tear etc. Function.
使用袋泡茶包装机的注意事项及袋泡茶包装机常见故障与排除方法
三、内外袋带线带标袋泡茶包装机,内外袋袋泡茶包装机的主要技术参数:Line inside and outside the bag with the tea bag packing machine, bag tea bag packaging machine inside and outside the main technical parameters:
号:SN-169 Model: SN - 169
封口形式:三边封     计量范围: 1-15克/    生产能力:30-60/分钟
Sealing form: three edge-sealing   measuring range: 1-15 g/bag   production capacity: 30 to 60 bags/min
内袋尺寸:长50-75㎜;宽50-75 外袋尺寸:长85-120㎜;宽75-95㎜
The bag size: 50-75 ㎜ long; Wide 50-75 ㎜ outside bag size: 85-120 ㎜ long; 75-95 ㎜ wide
标签尺寸:25X25(长*宽)  输入电源:220V/50HZ单相   总功率: 3.7kw
Label size: 25 x25 (length * width)  input power: 220 v / 50 hz single-phase   total power: 3.7 kw
整机重量:650KG     外型尺寸:1050X700X1300(长**高mm)
